Ptfe ring packing has high flux, low resistance, high separation efficiency and flexibility of operation.

● high temperature - long - term service temperature of 200~260 degrees
● low temperature resistance - still soft at -100 degrees
Resistance to corrosion resistance to aqua royalty and all organic solvents and inorganic compounds (except elemental fluorine, chlorine trifluoride and molten alkali metals)
● weather resistance - anti-aging in plastics.
● non-toxic pair of biological non-toxic also has more excellent chemical properties and chemical stability, is to make up for non-ferrous metals, various alloys can not solve the anti-corrosion, sealing and other aspects of the most ideal materials.

| name | PTFERaschig ring | |||
| material | PTFE | |||
| size | area | Void | pieces/ m3 | Packing |
| mm | m2/m3 | % | Kg/m3 | |
| 20*20*2 | 267 | 92.8 | 125000 | 550 |
| 25*25*2 | 219 | 93.4 | 60000 | 450 |
| 38*38*2.5 | 165 | 94.6 | 15800 | 420 |
| 50*50*4 | 108 | 94.5 | 6800 | 450 |
| 65*65*5 | 84 | 94.8 | 4600 | 500 |
| 76*76*4 | 73 | 92 | 2000 | 300 |
